2835 Injection LED Module, 3LED, IP65, DC12V

Home >Products >LED Signage Modules

2835 Injection LED Module 3LED IP65

Short Description

name: 2835 Injection LED Module 3LED IP65
Model: 2835-IJ-W3SMD

Buy IP65 Injection LED Module from China LED Light Manufacturer Haichang Optotech, 3 pcs of 2835 SMD LED, 66 Lm lumens, DC12V, 2-year warranty.



Super bright 2835 SMD LED
Aluminum PCB board, better heat dissipation
High quality ABS material, formed through injection molding process
Beautiful appearance, Waterproof, Anti-fire
DC 12v low voltage drive, very safe, low power consumption, 50,000 hours long lifetime
3M tape on back, reserved mounting hole, easy to install into the light box, maintenance—free
Solid-State, High Shock and Vibration Resistant
2-year warranty

Technical details:

Power: 0.72W/pc
Light source:  3 pcs of 2835 SMD LED
Housing: ABS
Lumens: 66 Lm
Beam degree: 120°
Operation Voltage: DC12V
IP Degree: IP 65
Colors available: white, warm white, red, blue, green, yellow
Max connection Quantity: 40pcs
Dimension: 73*15 mm
Normal working temperature : -30℃~50℃
Certificate: CE, ROHS


Our Injection LED module is widely used in:
1) Backlighting for channel letters and advertisement signage or light box
2) Decorations lights for entertainment places such as disco, KTV, bars and night clubs
3) Decoration for Events and shows
4) Decoration for pool, fountains or waterfall
5) Task lighting or marine signal


1. Outer carton: 52x37x26cm ;  Anti-static bag: 305x280x0.12mm .
2. 40pcs per chain, 2 chain in one Anti-static bag . ( 80 pcs in one Anti-static bag)
3. 30 bags in one carton . ( 2400 pcs in one carton)
4. Net weight: 19.5kg     Gross weight: 20.3kg/carton
